Measuringinstructions

Longandfailure-freeoperationofawindowshutterdependsnotonlyitshighqualitybutalsooncorrectfitandinstallation.Tomakethecoverfitperfectly,thechosenplaceneedstobecorrectlyandcarefullymeasured.
Youneedtostrictlyfollowthebelowsupportivedrawing:

Fittinginsideawindowrecess
  • A-WIDTHOFTHERECESSIftherecesswidthisnotthesameinallspots,thelowestdimensionoftherecessshouldbeassumed.5mmisthedistancethatneedstobesubtractedfromthewindowrecesswidthinordertoinstalltheverticalblindfreely.
  • B-HIGHOFTHERECESSIftherecessheightisnotthesareinallspots,thelowestdimensionoftherecessshouldbeassumed.5mmisthedistancethatneedstobesubtractedfromthewindowrecessheightinordertoinstalltheverticalblindfreely
    • *Rememberthatwhentheblindsarerolledup,theheightofthemechanismwillincreasebythethicknessofthelamellapackage,whichinsomecasesmayinterferewiththeopeningofthewindow.

    *Theheightsofthelamellapackagescanbefoundinthedescriptionsoftheblinds.

    Fittingoutsideawindowrecess
  • A-WIDTHOFTHEBLINDS
  • B-HEIGHTOFTHEBLINDS
  • C-WIDTHOFTHERECESS
  • D-HEIGHTOFTHERECESS

    • Usethisoptionifyouwantinstallthevenetianblindoutsidewindowrecess,Wesuggestthattheblindis8-10cmwidereachsidethanwindowrecess,alsoadd8-10cmaboveandbelowwindowtobesurethattheblindwillcoverthewindow.

    Non-invasiveinstallationonthewindowsash
  • A-WIDTHItisthewidthoftheglasstogetherwiththeglazingbeads.
  • B-HEIGHTThisistheheightofthewindowsash
  • I-WINDOWFRAME
  • II-GLAZINGBEAD
  • III-GLASS
    • Theheightofthelouverpackageafterbeingrolleduptogethertothetopprofileandthebottomprofile


    toprail52mm
    bottombeam18mm

    50/Pure
    ropeladder

    beltladder

    Africa&Shade
    ropeladder

    beltladder

    Bambù
    ropeladder

    beltladder

    *Itshouldbetakenintoaccountthattheheightofthetoprailandbottombeamisfixedandfor50mmblindsitamountstoatotalof70mm.

    Maximumdimensions:
    • MaximumwidthofBasswoodandPureblinds–270cm(2700mm)
    • Maximumwidthofbambooblinds–240cm(2400mm)
    • MaximumwidthofAfrica&Shadeblinds–290cm(2900mm)
    • Maximumheightforall–420cm(4200mm)

    *Ifthesystemsurfaceareaapproaches3m²,itmaybenecessarytouseanelectricdrive.

    *Uponindividualrequest,wecanmanufactureblindsincolours:20,21,41,42,45,61,68uptoawidthof3600mm.Insuchcases,pleasecontactus.

    *Alldimensionsaregiveninmillimeters

    **Theremaybeslightdifferencesintheheightoftheblinds.Thetoleranceofdifferencesisfrom-5mmto+35mm.
